Y Strainer Brass/Stainless Steel 3/8" - 4" BSP

Printer Friendly Page
Skip to Technical Details
Skip to Description
Skip to Prices

Description

Y Strainers made from Brass, Bronze and stainless steel suitable for a wide range of applications in industry.

Available with female parallel BSP (G) threads.

Technical Details

Brass/Bronze:	500 micron (1/4" - 2")
	800 micron (2 1/2" - 4")
	-20 to +110 deg C

	Brass (up to 2 1/2")
	Bronze (3" & 4")

Stainless Steel:	1mm holes 2mm apart
	-40 to +230 deg C

Datasheets

Y Strainer Brass/Stainless Steel 3/8 - 4 BSP datasheet

Click Here

Prices (Click quantity for more availability info)

	Female BSP Thread	Max Pressure	Order Code	Available	Each
Y Strainer - Brass/Bronze
	G1/4"	20 Bar	140741	2	£5.90
	G3/8"	20 Bar	140742	2	£5.90
	G1/2"	20 Bar	140743	8	£5.98
	G3/4"	20 Bar	140744	3	£9.83
	G1"	20 Bar	140745	6	£15.27
	G1 1/4"	20 Bar	140746	2	£23.32
	G1 1/2"	20 Bar	140747	3	£30.98
	2" BSP	20 Bar	140748	1	£52.72
	G2 1/2"	16 Bar	140749	0	£99.17
	G3"	16 Bar	140750	0	£141.77
	G4"	16 Bar	140751	0	£275.28
Y Strainer - Stainless Steel
	G1/4"	40 bar	140752	0	£33.05
	G3/8"	40 bar	140753	0	£33.05
	G1/2"	40 bar	140754	2	£33.05
	G3/4"	40 bar	140755	0	£39.62
	G1"	40 bar	140756	1	£55.07
	G1 1/4"	40 bar	140757	0	£74.92
	G1 1/2"	40 bar	140758	0	£88.02
	G2"	40 bar	140759	0	£121.17

(All Prices Exclude VAT)
