Description
Jubilee High Torque Clips are suitable for heavy duty applications with plastic or reinforced hoses.
The high clamping forces make this clip suitable for heavy duty applications where stubborn leakage or vibration issues make lesser clips and clamps unsuitable.
Jubilee High Torque clips are made of 316 stainless steel, with a two part housing and cut through band, keeping the band straight at the point of engagement and fully engaging all of the screw thread; giving a superior tightening torque.
Although not suitable for use on soft hoses, where the high forces and perforated band may cut into the hose, they are ideal where a high clamping force is required and with a flexible band material they can achieve a high level of friction even against a smooth surface such as a metal pole.
Jubilee High Torque Clips in 316 stainless steel are ideal for heavy duty applications in marine, offshore and industrial applications, where high corrosion resistance is required.
The flexible band also offers better sealing at lower torques than nut and bolt style heavy duty clamps, which, combined with weight saving benefits, make Jubilee High Torque Clips a versatile and superior heavy duty clamp.
Technical Details
|
Datasheets Click Here |
